BF4096
BioTeke
A. Description
BioTeke Sample Transfer Processing System BF4096, as a sample pre-processing workstation, is able to transfer 96 samples from single tubes to a 96-well plate in an automatic and accurate manner in 9-12 minutes. It integrates automatic barcode identification, decapping, liquid transfer, loading and capping of sample tubes, greatly improving large-scale nucleic acid testing capacity.
Scope of application: clinical sample processing, virus sample processing, microbiological test, nucleic acid test pre-processing, pharmaceutical development, biological sample filling, etc.
B. Characteristic
It is suitable for virus sampling tubes of multiple sizes. Up to 96 original tubes, without any pretreatment, can be loaded for four-channel barcode identification, decapping, liquid transfer, decapping. The channel spacing is flexible, fully adapting to the spacing of different plate tubes. With a collection volume of more than 10,000 samples per day, this highly automatic system can liberate researchers from heavy manual work.
The instrument covers a floor area of about 0.7 m2. Equipped with an upward-opening electric automatic door, it makes full use of the upper space of the laboratory.
C. Advantages
With an independent four-channel decapping module and an effective transfer volume of 10-1000 μL, the automatic sample transfer processing system offers fast and accurate operation as it incorporates tedious manual sample pre-processing steps into a closed system; besides, the built-in HEPA filter and UV sterilizer ensure a safe and reliable working environment.
The independent HEPA filter avoids the leakage of aerosol and improves security; two built-in UV lamps and an external droplet plate offer multiple protection, to ensure stable and reliable test results.
The four scanning modules are compatible with both QR codes and barcodes. In order to avoid missing, sample tubes will be quickly rotated, then identified and collected for information, and registered.
D. Basic Parameters
| Function | Sample Transfer | Work Environment | Closed sample processing |
| Application Parameters | 96 samples/9-12 min | Anti-contamination Design | External droplet plat |
| Sample Throughput | 96 samples/run | Capability | 10μL~1000μL |
| Safety Protection | UV lamp, HEPA system | Principle of Liquid Transfer | Air displacement |
| Barcode Scanning | Four 2D scanners,compatible with 1D and 2D | ||
| Robot Arm Positioning Accuracy | X-Y-Z:±0.1 mm | ||
| Sample Type | Plasma, serum, whole blood, swab wash buffer, etc. | ||
| Overall Dimension | 1300 mm (L) x 660 mm (W) x 720 mm (H) | ||
| Repeatability of Transfer | 10μL:≤5%, 100μL:≤2%,1000μL:≤1% | ||
| Information Loading | Automatic identification of sample tube barcode | ||
| Transfer Accuracy | 10μL:≤7%,100μL:≤5%,1000μL:≤2% | ||
| Tube Compatibility | Virus sampling tubes of multiple sizes,10 ml sample tubes,5 ml sample tubes (optional) | ||
E. Product Qualifications（By Dec.2nd,2022）
| Automated Sample Transfer Processing System 分杯处理系统 BF4096 | |
| CE Certification – CIBG Registration Letter | CE 证书-CIBG 注册信 |
| CE Certification –CIBG Registration Prove | CE 证书-CIBG 网站注册证明 |
| CE Certification–EC Declaration of Conformity | CE 证书-EC 符合性声明 |
| FDA Registration | FDA 注册 |
| CFDA(NMPA) Registration | CFDA(NMPA) 注册 |
| Certificate for Exportation of Medical Products | 出口销售证明 |
| Free sale certificate-United Arab Emirates | 自由销售证明-阿联酋 |
| Free sale certificate-Saudi Arabia | 自由销售证明-沙特阿拉伯 |
| Free sale certificate-Malaysia | 自由销售证明-马来西亚 |
| Free sale certificate-Mexico | 自由销售证明-墨西哥 |
| Free sale certificate-Indonesia | 自由销售证明-印尼 |
| ISO 13485 Certificate | ISO 13485 证书 |
| ISO 9001 Certificate | ISO 9001 证书 |
| ISO 45001 Certificate | ISO 45001职业健康安全管理体系认证证书 |
| ISO 14001 Certificate | ISO 14001环境管理体系认证证书 |
| IPMS Certificate | 知识产权管理体系认证证书 |
